Yale Digital Keypad Door Lock

£49.00
  • In StockIn Stock
  • FREE Delivery Tomorrow
  • Order Now Fri 27th May
Yale keypad lock with user-defined PIN for mechanical keyless entry. Easy to fit and use.
View Full Specification
  • Suitable for internal doors.
  • 60mm backset.
  • Code free access via a latch holdback.
  • Non Sequential code over 8,191 possible combinations.
  • Reversible allowing fitting on left or right hand hung doors.
  • No batteries required.
  • Size: 142 x 40 x 80mm (HxWxD)
Ref: YL-P-DL02-SC
Details
Dimensions
Height
142mm
Width
40mm
Depth
80mm
Backset
60mm
Door Thickness
35mm - 50mm
Lock
Lock Type
Latch (included)
Latchbolt
Reversible
PIN Code Qty
1
PIN Length
4 - 6 digits
Possible Combinations
8,191
PIN Code Entry
Non Sequential
Battery Powered
No
Yale Push Button Door Lock User Guide
Download
Features
Type
Mechanical
Colour
Satin Chrome
Weather Resistant
No
Internal Doors
Yes
External Doors
No
Code Free Access
Latch Holdback
Fast Code Change
No
Restricted PIN Access
No
Operation
Outside Operation
PIN Code
Inside Operation
Free Exit
Outside Handle Type
Knob
Inside Handle Type
Stubby Handle
Handed
Left, Right
Reviews [11]
Rated 8.9 / 10Rated 8.9 / 10Rated 8.9 / 10Rated 8.9 / 10Rated 8.9 / 10

4.5 / 5

Sort by:
Yale Digital Keypad Door Lock
Verified Customer June 2015
Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10 5 / 5
Recommended

lets pretend this is a banana

now take a pile of bananas and put this on the top

now we have what this product is - Top banana

Was this helpful? 17

Yale Digital Keypad Door Lock
Verified Customer March 2015
Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10 5 / 5
Recommended

I have fitted many types of security lock in the past, but this product I found to be excellent in every aspect. From the ease and versatility of fitting, the overall quality and finish of the system. I fitted this particular push-button lock to an office door and the staff tell me that it is so easy to use and they now have complete confidence in the security it affords. Well done.

J Y

Was this helpful? 10

Yale Digital Keypad Door Lock
Verified Customer May 2015
Rated 5.6 / 10Rated 5.6 / 10Rated 5.6 / 10Rated 5.6 / 10Rated 5.6 / 10 2.8 / 5
Recommended

Arrived promptly. After fitting I noticed that lock could be opened without entering code due to some play in mechanism before lock engages. Due to space between door and frame being slightly too large. Fixed after adjustment. Locking mechanism not always engaging when closing door. I always have to check whether door is locked. Thus lock is not very reliable.

It feels a bit cheaply constructed. If I have to replace it I will consider a slightly sturdier, more expensive lock

I am very happy with the service I got from The Safe Shop. Will purchase from them in future.

Was this helpful? 9

Yale Digital Keypad Door Lock
Verified Customer August 2015
Rated 8 / 10Rated 8 / 10Rated 8 / 10Rated 8 / 10Rated 8 / 10 4 / 5
Recommended

works fine

Was this helpful? 8

Yale Digital Keypad Door Lock
Verified Customer March 2016
Rated 8.4 / 10Rated 8.4 / 10Rated 8.4 / 10Rated 8.4 / 10Rated 8.4 / 10 4.2 / 5
Recommended

Firs of all the website, very nice design and easy to use navigation throughout the website with the search options set out in a nice fashion . The item came promptly with no issues with the product or packaging and arrived well in the the estimated delivery time. The product itself is very easy to use and set up with no issues. The lock is currently in use and works perfectly due to the product being a good quality and build. For anyone looking to purchase off this website you should have no worries as it is a very good reliable website.I would highly recommend.

Was this helpful? 6

Yale Digital Keypad Door Lock
Verified Customer July 2020
Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10 5 / 5
Recommended

Very pleased with the product

Was this helpful? 3

Yale Digital Keypad Door Lock
Verified Customer June 2019
Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10 5 / 5
Recommended

I am not very good at remembering to take essentials with me when I leave the house and this includes keys. However I can remember numbers so having a combination lock instead of a key lock is incredibly helpful. I bought the Yale Digital Keypad Door Lock and found that it did everything it was advertised to do, it was very easy to fit, the design is stylish and functional and the buttons on the keypad are large enough for ‘older fingers’ to be able to use without difficulty. I was also impressed with the ease of ordering the product and the speed of delivery. All in all a very satisfactory service.

Was this helpful? 3

Yale Digital Keypad Door Lock
Verified Customer January 2016
Rated 7.8 / 10Rated 7.8 / 10Rated 7.8 / 10Rated 7.8 / 10Rated 7.8 / 10 3.9 / 5
Recommended

Our handyman found the first one really fiddly to fit but once he'd done one he was fine.

I wouldn't try to fit one personally but with reasonable skills.

I think there is a way of changing the numbers so that you can remember one code & the others follow from there but we haven't been brave enough yet.

It's something to look at. I love them.

Was this helpful? 2

Yale Digital Keypad Door Lock
Verified Customer April 2015
Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10 5 / 5
Recommended

Really good value for money excellent product

Was this helpful? 2

Yale Digital Keypad Door Lock
Verified Customer December 2018
Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10 5 / 5
Recommended

This is a great little lock and saves having to have keys to open the door. There are no electronics and batteries, so there is really nothing to go wrong or worry about. As this model now has a latch to keep the door open it is even better than older versions that didn’t have a latch.

You can change the combination quite easily when fitting the lock so you can choose whatever you want and there are plenty of combinations including letters as well as numbers.

Quite frankly it is everything you could want in a digital lock and we now have two of them, and would strongly recommend.

Was this helpful? 1

Yale Digital Keypad Door Lock
Verified Customer July 2020
Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10 5 / 5
Recommended

Very pleased with the product

Was this helpful? 3

Yale Digital Keypad Door Lock
Verified Customer June 2019
Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10 5 / 5
Recommended

I am not very good at remembering to take essentials with me when I leave the house and this includes keys. However I can remember numbers so having a combination lock instead of a key lock is incredibly helpful. I bought the Yale Digital Keypad Door Lock and found that it did everything it was advertised to do, it was very easy to fit, the design is stylish and functional and the buttons on the keypad are large enough for ‘older fingers’ to be able to use without difficulty. I was also impressed with the ease of ordering the product and the speed of delivery. All in all a very satisfactory service.

Was this helpful? 3

Yale Digital Keypad Door Lock
Verified Customer May 2019
Rated 8.4 / 10Rated 8.4 / 10Rated 8.4 / 10Rated 8.4 / 10Rated 8.4 / 10 4.2 / 5
Recommended

Arrived in quick time , Quality is very good, Been installed for 5 months

and had no problems with it .

Was this helpful?

Yale Digital Keypad Door Lock
Verified Customer December 2018
Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10 5 / 5
Recommended

This is a great little lock and saves having to have keys to open the door. There are no electronics and batteries, so there is really nothing to go wrong or worry about. As this model now has a latch to keep the door open it is even better than older versions that didn’t have a latch.

You can change the combination quite easily when fitting the lock so you can choose whatever you want and there are plenty of combinations including letters as well as numbers.

Quite frankly it is everything you could want in a digital lock and we now have two of them, and would strongly recommend.

Was this helpful? 1

Yale Digital Keypad Door Lock
Verified Customer March 2016
Rated 8.4 / 10Rated 8.4 / 10Rated 8.4 / 10Rated 8.4 / 10Rated 8.4 / 10 4.2 / 5
Recommended

Firs of all the website, very nice design and easy to use navigation throughout the website with the search options set out in a nice fashion . The item came promptly with no issues with the product or packaging and arrived well in the the estimated delivery time. The product itself is very easy to use and set up with no issues. The lock is currently in use and works perfectly due to the product being a good quality and build. For anyone looking to purchase off this website you should have no worries as it is a very good reliable website.I would highly recommend.

Was this helpful? 6

Yale Digital Keypad Door Lock
Verified Customer January 2016
Rated 7.8 / 10Rated 7.8 / 10Rated 7.8 / 10Rated 7.8 / 10Rated 7.8 / 10 3.9 / 5
Recommended

Our handyman found the first one really fiddly to fit but once he'd done one he was fine.

I wouldn't try to fit one personally but with reasonable skills.

I think there is a way of changing the numbers so that you can remember one code & the others follow from there but we haven't been brave enough yet.

It's something to look at. I love them.

Was this helpful? 2

Yale Digital Keypad Door Lock
Verified Customer August 2015
Rated 8 / 10Rated 8 / 10Rated 8 / 10Rated 8 / 10Rated 8 / 10 4 / 5
Recommended

works fine

Was this helpful? 8

Yale Digital Keypad Door Lock
Verified Customer June 2015
Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10 5 / 5
Recommended

lets pretend this is a banana

now take a pile of bananas and put this on the top

now we have what this product is - Top banana

Was this helpful? 17

Yale Digital Keypad Door Lock
Verified Customer May 2015
Rated 5.6 / 10Rated 5.6 / 10Rated 5.6 / 10Rated 5.6 / 10Rated 5.6 / 10 2.8 / 5
Recommended

Arrived promptly. After fitting I noticed that lock could be opened without entering code due to some play in mechanism before lock engages. Due to space between door and frame being slightly too large. Fixed after adjustment. Locking mechanism not always engaging when closing door. I always have to check whether door is locked. Thus lock is not very reliable.

It feels a bit cheaply constructed. If I have to replace it I will consider a slightly sturdier, more expensive lock

I am very happy with the service I got from The Safe Shop. Will purchase from them in future.

Was this helpful? 9

Yale Digital Keypad Door Lock
Verified Customer April 2015
Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10Rated 10 / 10 5 / 5
Recommended

Really good value for money excellent product

Was this helpful? 2



Delivery

Select during checkout


Filter by
Popular Delivery Options
Next / Named Day Delivery to your front door on a day of your choice
Order Now Get It Fri 27th May
Mon-Fri
8am - 6pm
FREE
Mon-Fri
8am - 6pm
FREE
Scottish Highlands Delivery Includes doorstep drop off deliveries to the following Highlands post codes, no steps: AB30-38, AB44-56, FK17-99, G83, IV1-39, IV52-54, IV63, KW1-14, PA21-33, PA34-40, PH18-26, PH30-41, PH49-50
Mon-Fri
1 - 2 Days
8am - 6pm
FREE
Mon-Fri
1 - 2 Days
8am - 6pm
FREE
Isle of Wight Delivery Our standard doorstep drop off service, no steps
Mon-Fri
1 - 2 Days
8am - 6pm
FREE
Mon-Fri
1 - 2 Days
8am - 6pm
FREE
Isle of Man Delivery Our standard doorstep drop off service, no steps
Mon-Fri
2 - 3 Days
8am - 6pm
FREE
Mon-Fri
2 - 3 Days
8am - 6pm
FREE
Isles of Scilly Delivery Our standard doorstep drop off service, no steps
Mon-Fri
2 - 3 Days
8am - 6pm
FREE
Mon-Fri
2 - 3 Days
8am - 6pm
FREE
Scottish Islands Delivery Includes doorstep drop off deliveries to the following Scottish Island post codes, no steps: HS1-9, IV40-51, IV55-56, KA27-28, KW15-17, PA20, PA41-49, PA60-78, PH42-44, ZE1-3
Mon-Fri
2 - 3 Days
8am - 6pm
FREE
Mon-Fri
2 - 3 Days
8am - 6pm
FREE
Northern Ireland Delivery Our standard doorstep drop off service, no steps
Mon-Fri
1 - 2 Days
8am - 6pm
FREE
Mon-Fri
1 - 2 Days
8am - 6pm
FREE
Guernsey Delivery Our standard doorstep drop off service, no steps
Mon-Fri
2 - 3 Days
8am - 6pm
FREE
Mon-Fri
2 - 3 Days
8am - 6pm
FREE
Jersey Delivery Our standard doorstep drop off service, no steps
Mon-Fri
2 - 3 Days
8am - 6pm
FREE
Mon-Fri
2 - 3 Days
8am - 6pm
FREE
Weekend Delivery to your front door on a Saturday of your choice
Sat
8am - 6pm
£1.50
Sat
8am - 6pm
£1.50
Indoor Delivery Options
Delivery & Install Options
Returns

Returns

Replacements
If you are not completely satisfied with your purchase, simply return the item to us in its original condition and packaging within 14 days of receipt and we will issue a full refund, excluding upgraded delivery services.
More information about returns
FAQs [11]

FAQs (11)

» Ask Question


Is there a type of push button lock suitable for use with an internal sliding door?
Pete, Leicester
Sliding doors require a hookbolt in order to lock correctly. We would recommend the Lockey 2500 - Sliding Door lock, which is perfect for that application.
Jonathan P
Was this helpful? 14

Can this type of lock be used on an outside door?
Isabel Morgan , Bristol
No, This unit is not weather resistant however I can suggest an alternative model by codelocks Codelocks CL255.
Tom W
Was this helpful? 15

How do you set the code?
Barry, York
The code can be changed by swapping around the red and blue tumblers on the inside of the exterior code pad. Enter the red tumblers into the numbers that you wish to incorporate into your code. See the detailed Yale Push Button User Guide for step by step instructions.
Jonathan P
Was this helpful? 17

Does this lock have a fire rating. Can it be used on a fire door?
Graham Cooper, Droitwich
The lock does not have a fire rating. You could purchase the Codelocks CL255 (Stainless Steel) with an intumescent fire kit, which can be purchased in the list of accessories. The combination of lock and fire kit would be suitable for fire doors.
Tom W
Was this helpful? 14

Can you confirm that no power (electric wiring) is required to operate this lock?
Don, Craigavon
All mechanical digital door locks, including this one, require no power or electric wiring to operate.
Jonathan P
Was this helpful? 16

Hi, for my insurance, does it comply to BS3621 standard? Thank you
Anonymous
The Yale Push Button Door Lock is not insurance approved. You will need to use an insurance approved deadlock in conjunction with this push button lock to comply with the BS3621 standard.

Jonathan P
Was this helpful? 18

I've kept to the instructions and when replacing the handing pin plate, the pin sticks up, the plate is not sitting flat and screws wont align up.
simon, chatham
When replacing the tumblers, to set your own code, there are some important steps that you must take. Do not leave any tumbler position empty. Before changing codes, the "C" button must be depressed and held in the down position throughout the code changing procedure and the red and blue tumblers must be the correct way up as per the user guide.
Jonathan P
Was this helpful? 14

We have an old one of these in one of our properties (we are a property company) and the door has shut and locked. Nobody knows the combination to it - how can we get it open again without the combination?
VJ, Chelmsford
The only way to gain access is by entering the code. There is no override code that can bypass the code that has been set. This is a security benefit for this type of product and is designed to deter personnel from entering who do not know the code.
Jonathan P
Was this helpful? 16

How can I confirm this lock will be able to replace the existing one in the room? Which measurements do I need to take to ensure they are compatible?
Michael Kardamakis, London
This lock is operated by a latch that has a 60mm backset (The measurement from the edge of the door to the centre of the handle). Check the backset measurement on your door to see if this will work.

Another important factor is, this lock is suitable for doors where the thickness is between 35mm - 50mm.
Jonathan P
Was this helpful? 18

Does this have a nightlatch feature so that someone inside can leave it unlocked?
Anonymous
This lock does include a latch holdback feature. Although not visible on the image, behind the handle there is a switch that allows you to hold the latch in place to that the door can be opened without the PIN code.
Anthony N
Was this helpful? 20
Help & Advice

Related Blog Articles

Get in Touch

Chat to an Expert online
Call an Expert 0800 432 0722.

We're here Mon-Fri, 9am-5pm.


Pay Later

Pay in 30 Days

Get your goods before you pay with Pay in 30 Days by Klarna. Sit back and relax and let Klarna notify you when payment is due. More information

Rep. APR (variable) 0%
Pay Now £0.00
Pay 25th Jun £49.00
Total Payable £49.00

Pay in Instalments

Seen something you want, but not got the cash just yet? Klarna's Slice It allows you to split the cost over multiple months at no additional cost. More information

Now £16.33
25th Jun £16.33
25th Jul £16.34

Customers also bought...
